A trailer with configurable audio-visual and network systems in a climate-controlled environment. The trailer has two sides separated by a wall and accessed through separate doors. It is fully networked with switches and an LTE modem is available for internet connectivity. Patch bays, cable pass throughs and cable trays allow connection from the outside keeping equipment and operators isolated and safe.

     12’x6’ • Non-descript white exterior • HVAC • Solar powered internal and exterior lights • LTE internet connection • 2 Control Areas • Secure

What can you do with the MAVP?

The flexibility of the setup will accommodate live streaming and recording. It can serve as the hub of your production or provide distribution onsite and virtually. Stream your live event to a custom live broadcast stream to HTTP, HTTPS or RTSP.

 How is the MAVP Setup?

Each side of the trailer has trunked switches with VLANs, supporting networking and Dante. Audio, video, antenna, and network connections are labeled and terminated inside the trailer and connect to external, labeled patch bays. Large format audio consoles can be housed on the audio work surface. A range of productions can be supported with the on-board audio and video monitors, video router, video switcher, web presenter, PC’s and vMix PRO.

3 Available Configurations

    1, Open Configuration

          This is a basic setup with standard connections. The end user is responsible for connectivity and operation.

    2. Designed Configuration

          This configuration is setup in pre-production. The end user provides the workflow and review’s the setup. Operation during the

          event/production is performed by the end user.

   3. Supported Configuration

         In this configuration the trailer is setup in pre-production and an engineer is on site during the event/production.

Inventory

Audio

Yamaha TF 1/Tio

Yamaha H5 Monitors

Halfer ME Monitors

Berhinger PowerPlay 8

Focusrite Scarlet

Network

2-Cisco SG30010 Routers (1-POE)

SG30028 POE

Cat 6 Patch Bay

Power

Furman M-8L, SMP

Cyber Power PDU 15B8R

2- APC Backup 250

Computers

PC i7

PC i3

Accessories

Stream Deck

Stream Deck XL

Video

Decimators DMON 4s, 2 MD-LX,

BlackMagic Studio HD, Web presenter, 12x12 Router, 4 HDMI HDMI=SDI Converters

Online Setup

Online routing provides an over-view of connections.

How do I book the MAVP Trailer?

 1. Confirm your date.

 2. Pick your configuration.

 3. Receive your estimate.

All of the steps can be completed at this link.
